Winters PPC5071 Process Gauge, 0-1500 psi/kPa, 1/2" NPT Bottom Connection

Model: PPC5071 | UPC: 628311222579

Be the first to review this product

Winters PPC5071 Process Gauge, 0-1500 psi/kPa, 1/2&quot; NPT Bottom Connection-

Image is for reference only, refer to product info for complete details.

Downloads: datasheet

More Winters Products

Ask an Expert

Winters PPC5071 Process Gauge, 0-1500 psi/kPa, 1/2" NPT Bottom Connection

Model: PPC5071 | UPC: 628311222579

Be the first to review this product

Features a solid phenolic front and polypropylene pressure relief back safety case, along with a micrometer adjustable pointer for ease in calibration. It has a pressure range of 0 to 1500 psi/kPa, ±0.5% accuracy, stainless steel socket and tube, and a 1/2" NPT bottom connection.

Sale Price	$139.57 USD
Regular Price	$253.76 USD
Availability	2 to 3 Weeks2 to 3 Weeks
Quantity	Quantity

Traceable Calibration Certificate for your PPC5071 Process Gauge

Yes, I would like to add a Traceable Calibration Certificate (Model CERTIPG1) for only $110.00 USD

Traceable Calibration Certificate for your PPC5071 Process Gauge

Yes, I would like to add a Traceable Calibration Certificate (Model CERTIPG1) for only $110.00 USD

Winters PPC5071 Offers

Features

Solid phenolic front and polypropylene pressure relief back safety case
Field liquid-fillable (bottom connection only)
Stainless steel full rotary movement for longer life
Micrometer adjustable pointer for ease in calibration
Under and overload stops
316L stainless steel wetted parts
Restricted orifice standard on dual scale (optional on single scale)
0.5% accuracy
ASME B40.100 compliant
RoHS compliant (SS and Monel® internals only)
CRN registered
5 year warranty

Applications

Used where operator safety is a must
Ideally suited for process, chemical and petroleum industries
Highly corrosive media

Winters PPC5071 Specifications

Dial	4.5" (115mm) white aluminum with black and red markings
Case	Black phenolic with pressure relief back, solid front, integral back flange
Solid Wall	Phenolic
Pressure Relief Back	Polypropylene
Window	Polycarbonate
Pointer	Aluminum, anodized black, micrometer adjustable
Socket	316L SS
Connection	1/2" NPT - bottom
Process Temperature	-40 to 250°F (-40 to 120°C)
Enclosure Rating	IP65

Click here for complete specifications on the Winters PPC5071

What's included with the Winters PPC5071

Winters PPC5071 Process Gauge, 0-1500 psi/kPa, 1/2" NPT Bottom Connection

datasheet for the Winters PPC5071 Process Gauge, 0-1500 psi/kPa, 1/2" NPT Bottom Connection

Ask a question about Winters PPC5071 Process Gauge, 0-1500 psi/kPa, 1/2" NPT Bottom Connection

Customer Reviews for the Winters PPC5071

Description ➕➖

Winters PPC5071 Offers

Features

Solid phenolic front and polypropylene pressure relief back safety case
Field liquid-fillable (bottom connection only)
Stainless steel full rotary movement for longer life
Micrometer adjustable pointer for ease in calibration
Under and overload stops
316L stainless steel wetted parts
Restricted orifice standard on dual scale (optional on single scale)
0.5% accuracy
ASME B40.100 compliant
RoHS compliant (SS and Monel® internals only)
CRN registered
5 year warranty

Applications

Used where operator safety is a must
Ideally suited for process, chemical and petroleum industries
Highly corrosive media

Specifications ➕➖

Winters PPC5071 Specifications

Dial	4.5" (115mm) white aluminum with black and red markings
Case	Black phenolic with pressure relief back, solid front, integral back flange
Solid Wall	Phenolic
Pressure Relief Back	Polypropylene
Window	Polycarbonate
Pointer	Aluminum, anodized black, micrometer adjustable
Socket	316L SS
Connection	1/2" NPT - bottom
Process Temperature	-40 to 250°F (-40 to 120°C)
Enclosure Rating	IP65
