Winters PFP640 Premium Stainless-Steel Liquid Filled Pressure Gauge, 30" Hg Vac/kPa, SS internals

Model: PFP640 | UPC: 628311243307

Winters PFP640 Premium Stainless-Steel Liquid Filled Pressure Gauge, 30" Hg Vac/kPa, SS internals-

Image is for reference only, refer to product info for complete details.


Downloads: datasheet

Winters PFP640 Premium Stainless-Steel Liquid Filled Pressure Gauge, 30" Hg Vac/kPa, SS internals

Model: PFP640 | UPC: 628311243307

The premium stainless-steel, liquid-filled pressure gauge with 4" (10.2 cm) dial comes with a 0.25" (0.64 cm) bottom connection and a range of 30" Hg Vac/kPa. It is highly accurate with an accuracy rate of ±1% ANSI/ASME Grade 1A. It features stainless-steel internals and case that protects it against vibration and pulsation. Dual scale.

The premium stainless-steel, liquid-filled pressure gauge with 4" (10.2 cm) dial comes with a 0.25" (0.64 cm) bottom connection and a range of 30" Hg Vac/kPa. It is highly accurate with an accuracy rate of ±1% ANSI/ASME Grade 1A. It features stainless-steel internals and case that protects it against vibration and pulsation. Dual scale.

Sale Price $155.28 USD
Regular Price $282.32 USD
Availability 2 to 3 Weeks
Quantity

Winters PFP640 Offers

The premium stainless-steel, liquid-filled pressure gauges with 2.5" (6.4 cm) dial come with a 0.25" (0.64 cm) bottom connection. They are highly accurate with an accuracy rate of ±1.5% of full-scale value. These gauges feature stainless-steel internals and a case that protects against vibration and pulsation. Dual scale.

Features

  • Liquid-filled, stainless-steel case protects against vibration and pulsation
  • Highly accurate
  • Back, bottom or panel mounted
  • Under and overload stops
  • Ventable plug on 2.5" to 4.5" (6.35 to 11.4 cm) stainless-steel and 4.5" (11.4 cm) brass bottom mount and 4" (10.2 cm) stainless-steel back mount gauges
  • Stainless steel or brass wetted parts
  • Restrictor screw standard on dual scale (optional on single scale)
  • Dry case available
  • ASME B40.100 compliant (EN837-1 available)
  • RoHS compliant (SS internals only)
  • CRN registered
  • 5-year warranty

Applications

  • Outdoor And Severe Ambient And Process Conditions
  • Use Where Harmful Vibration And Pulsation Are Present
  • Hydraulic Equipment, Pressure Washers, Oil Field Equipment, Pumps, Compressors And Process Systems

Winters PFP640 Specifications

Range 30" Hg Vac/kPa
Connection 0.25" (0.64 cm) bottom
Movement/Socket/Tube Stainless steel
Dial 4" (100 mm) white aluminum with black and red markings
Case AISI 304 SS
Lens Polycarbonate, high pressure BSP(G) and HP: tempered safety glass
Fill Liquid Glycerin
Working Pressure Maximum 75% of full-scale value
Ambient Temperature -4 to 150°F (-20 to 65°C)
Accuracy ±1% ANSI/ASME Grade 1A
Click here for complete specifications on the Winters PFP640

What's included with the Winters PFP640

  • Winters PFP640 Premium Stainless-Steel Liquid Filled Pressure Gauge, 30" Hg Vac/kPa, SS internals

Ask a question about Winters PFP640 Premium Stainless-Steel Liquid Filled Pressure Gauge, 30" Hg Vac/kPa, SS internals

Customer Reviews for the Winters PFP640

Winters PFP640 Offers

The premium stainless-steel, liquid-filled pressure gauges with 2.5" (6.4 cm) dial come with a 0.25" (0.64 cm) bottom connection. They are highly accurate with an accuracy rate of ±1.5% of full-scale value. These gauges feature stainless-steel internals and a case that protects against vibration and pulsation. Dual scale.

Features

  • Liquid-filled, stainless-steel case protects against vibration and pulsation
  • Highly accurate
  • Back, bottom or panel mounted
  • Under and overload stops
  • Ventable plug on 2.5" to 4.5" (6.35 to 11.4 cm) stainless-steel and 4.5" (11.4 cm) brass bottom mount and 4" (10.2 cm) stainless-steel back mount gauges
  • Stainless steel or brass wetted parts
  • Restrictor screw standard on dual scale (optional on single scale)
  • Dry case available
  • ASME B40.100 compliant (EN837-1 available)
  • RoHS compliant (SS internals only)
  • CRN registered
  • 5-year warranty

Applications

  • Outdoor And Severe Ambient And Process Conditions
  • Use Where Harmful Vibration And Pulsation Are Present
  • Hydraulic Equipment, Pressure Washers, Oil Field Equipment, Pumps, Compressors And Process Systems

Winters PFP640 Specifications

Range 30" Hg Vac/kPa
Connection 0.25" (0.64 cm) bottom
Movement/Socket/Tube Stainless steel
Dial 4" (100 mm) white aluminum with black and red markings
Case AISI 304 SS
Lens Polycarbonate, high pressure BSP(G) and HP: tempered safety glass
Fill Liquid Glycerin
Working Pressure Maximum 75% of full-scale value
Ambient Temperature -4 to 150°F (-20 to 65°C)
Accuracy ±1% ANSI/ASME Grade 1A
Click here for complete specifications on the Winters PFP640

What's included with the Winters PFP640

  • Winters PFP640 Premium Stainless-Steel Liquid Filled Pressure Gauge, 30" Hg Vac/kPa, SS internals

Ask a question about Winters PFP640 Premium Stainless-Steel Liquid Filled Pressure Gauge, 30" Hg Vac/kPa, SS internals

Customer Reviews for the Winters PFP640
