The premium stainless-steel, liquid filled pressure gauge with 4" (10.2 cm) dial comes with a 0.5" (1.27 cm) back (LB) connection and a range of 0/2,000 psi/kPa. It is highly accurate with an accuracy rate of ±1% ANSI/ASME Grade 1A. It features brass internals and a stainless-steel case that protects it against vibration and pulsation. Dual scale.
The premium stainless-steel, liquid filled pressure gauge with 4" (10.2 cm) dial comes with a 0.5" (1.27 cm) back (LB) connection and a range of 0/2,000 psi/kPa. It is highly accurate with an accuracy rate of ±1% ANSI/ASME Grade 1A. It features brass internals and a stainless-steel case that protects it against vibration and pulsation. Dual scale.
Discontinued!
This product has been discontinued and is no longer available. There is no direct replacement. Don't worry, we have some options to help you find what you need:
Visit our Liquid Filled Pressure Gauges category for similar products.
Or let's do a search and help you find what you need:
The premium stainless-steel, liquid-filled pressure gauges with 2.5" (6.4 cm) dial come with a 0.25" (0.64 cm) bottom connection. They are highly accurate with an accuracy rate of ±1.5% of full-scale value. These gauges feature stainless-steel internals and a case that protects against vibration and pulsation. Dual scale.
Features
Applications
| Range | 0/20,000 psi/kPa |
| Connection | 0.5" (1.27 cm) bottom |
| Movement/Socket/Tube | Brass |
| Dial | 4" (100 mm) white aluminum with black and red markings |
| Case | AISI 304 SS |
| Lens | Polycarbonate |
| Fill Liquid | Glycerin |
| Working Pressure | Maximum 75% of full-scale value |
| Ambient Temperature | -4 to 150°F (-20 to 65°C) |
| Accuracy | ±1% ANSI/ASME Grade 1A |
| Range | 0/20,000 psi/kPa |
| Connection | 0.5" (1.27 cm) bottom |
| Movement/Socket/Tube | Brass |
| Dial | 4" (100 mm) white aluminum with black and red markings |
| Case | AISI 304 SS |
| Lens | Polycarbonate |
| Fill Liquid | Glycerin |
| Working Pressure | Maximum 75% of full-scale value |
| Ambient Temperature | -4 to 150°F (-20 to 65°C) |
| Accuracy | ±1% ANSI/ASME Grade 1A |
