Winters PEM291 Economy Gauge, 0 to 3000 psi/kPa

Model: PEM291 | UPC: 628311200751

Be the first to review this product

Winters PEM291 Economy Gauge, 0 to 3000 psi/kPa-

Image is for reference only, refer to product info for complete details.

Downloads: datasheet

More Winters Products

Ask an Expert

Winters PEM291 Economy Gauge, 0 to 3000 psi/kPa

Model: PEM291 | UPC: 628311200751

Be the first to review this product

Ideal for plumbing, heating, and air conditioning, this economy gauge features a case of steel, a 2.5" (63 mm) dial size, a ¼" bottom connection, and a range of 0 to 3,000 psi/kPa.

Sale Price	$14.62 USD
Regular Price	$26.58 USD
Availability	2 to 3 Weeks2 to 3 Weeks
Quantity	Quantity

Traceable Calibration Certificate for your PEM291 Economy Gauge

Yes, I would like to add a Traceable Calibration Certificate (Model CERTIPG1) for only $110.00 USD

Traceable Calibration Certificate for your PEM291 Economy Gauge

Yes, I would like to add a Traceable Calibration Certificate (Model CERTIPG1) for only $110.00 USD

Winters PEM291 Offers

Features

Most economical, all-purpose pressure gauge
1.5" (40 mm) to 4" (100 mm) sizes
Friction bezel rings
Black steel case
Brass or lead free brass wetted parts
±3-2-3% accuracy
ASME B40.100 compliant
CRN registered
Lead free version NSF-61-372 certified

Applications

General purpose gauge for plumbing, heating, air conditioning, pneumatic, hydraulic, water tanks, air compressors, OEM
Lead free version for potable water systems
Suitable for non-clogging and non-corroding media

Winters PEM291 Specifications

Dial	2.5" (63 mm)
Case	Steel, painted black
Lens	Acrylic
Ring	Steel, chrome plated
Socket	Brass
Connection	¼" NPT standard
Bourdon Tube	Phosphor bronze
Movement	Brass
Pointer	Aluminum, black
Welding	Silver alloy
Over-pressure Limit	25% of full scale value
Working Pressure	25% of full scale value
Ambient/Process Temperature	-40 to 150°F (-40 to 65°C)
Accuracy	±3-2-3% ANSI/ASME Grade B
Enclosure Rating	IP52

Click here for complete specifications on the Winters PEM291

What's included with the Winters PEM291

Winters PEM291 Economy Gauge, 0 to 3000 psi/kPa

datasheet for the Winters PEM291 Economy Gauge, 0 to 3000 psi/kPa

Ask a question about Winters PEM291 Economy Gauge, 0 to 3000 psi/kPa

Customer Reviews for the Winters PEM291

Description ➕➖

Winters PEM291 Offers

Features

Most economical, all-purpose pressure gauge
1.5" (40 mm) to 4" (100 mm) sizes
Friction bezel rings
Black steel case
Brass or lead free brass wetted parts
±3-2-3% accuracy
ASME B40.100 compliant
CRN registered
Lead free version NSF-61-372 certified

Applications

General purpose gauge for plumbing, heating, air conditioning, pneumatic, hydraulic, water tanks, air compressors, OEM
Lead free version for potable water systems
Suitable for non-clogging and non-corroding media

Specifications ➕➖

Winters PEM291 Specifications

Dial	2.5" (63 mm)
Case	Steel, painted black
Lens	Acrylic
Ring	Steel, chrome plated
Socket	Brass
Connection	¼" NPT standard
Bourdon Tube	Phosphor bronze
Movement	Brass
Pointer	Aluminum, black
Welding	Silver alloy
Over-pressure Limit	25% of full scale value
Working Pressure	25% of full scale value
Ambient/Process Temperature	-40 to 150°F (-40 to 65°C)
Accuracy	±3-2-3% ANSI/ASME Grade B
Enclosure Rating	IP52
