WIKA 50916629LF Pressure Gauge, 0 to 20000 PSI

Model: 50916629LF

Be the first to review this product

WIKA 50916629LF Pressure Gauge, 0 to 20000 PSI-

Image is for reference only, refer to product info for complete details.

More WIKA Products

Ask an Expert

WIKA 50916629LF Pressure Gauge, 0 to 20000 PSI

Model: 50916629LF

Be the first to review this product

For applications with high dynamic pressure pulsations or vibration. Suitable for corrosive environments and gaseous or liquid media that will not obstruct the pressure system.

Discontinued!

This product has been discontinued and is no longer available. There is no direct replacement. Don't worry, we have some options to help you find what you need:

Visit our Compound Pressure Gauges category for similar products.

Or let's do a search and help you find what you need:

WIKA 50916629LF Offers

Features

Excellent load-cycle stability and shock resistance
4.5" diameter dial size
Vacuum / Compound ranges to 400 psi (25 bar); Positive pressure ranges from 15 psi (1 bar) to 30,000 psi (2,000 bar)
Accuracy of ±0.5% of span; ±1.0% of span for 20,000 psi (1,600 bar) range and above
Single scales with large figures at beginning and end for quick and easy range identification
Glycerine filled case
Black fiberglass-reinforced thermoplastic (POCAN) case, solid front, blow out back, turret-style case with built in rear flange lugs
Clear acrylic window with Buna-N gasket
1/2" NPT lower mount process connection
Welded stainless steel safety gauge
All 316SS wetted parts
Weather resistant (NEMA 3/IP54) without membrane; weather tight (NEMA 4X / IP66) filled case with membrane installed

What's included with the WIKA 50916629LF

WIKA 50916629LF Pressure Gauge, 0 to 20000 PSI

Ask a question about WIKA 50916629LF Pressure Gauge, 0 to 20000 PSI

Customer Reviews for the WIKA 50916629LF

Description ➕➖

WIKA 50916629LF Offers

Features

Excellent load-cycle stability and shock resistance
4.5" diameter dial size
Vacuum / Compound ranges to 400 psi (25 bar); Positive pressure ranges from 15 psi (1 bar) to 30,000 psi (2,000 bar)
Accuracy of ±0.5% of span; ±1.0% of span for 20,000 psi (1,600 bar) range and above
Single scales with large figures at beginning and end for quick and easy range identification
Glycerine filled case
Black fiberglass-reinforced thermoplastic (POCAN) case, solid front, blow out back, turret-style case with built in rear flange lugs
Clear acrylic window with Buna-N gasket
1/2" NPT lower mount process connection
Welded stainless steel safety gauge
All 316SS wetted parts
Weather resistant (NEMA 3/IP54) without membrane; weather tight (NEMA 4X / IP66) filled case with membrane installed
