Meets the required specifications for diagnostic and educational use, this battery-powered clinical microscope is perfect for clinics, universities, and industrial laboratories. Comes in a monocular viewing head and objectives with 4x, 10x, 40x, and 100x magnification.
Meets the required specifications for diagnostic and educational use, this battery-powered clinical microscope is perfect for clinics, universities, and industrial laboratories. Comes in a monocular viewing head and objectives with 4x, 10x, 40x, and 100x magnification.
Discontinued!
This product has been discontinued and is no longer available. There is no direct replacement. Don't worry, we have some options to help you find what you need:
Visit our Magnifiers and Microscopes category for similar products.
Or let's do a search and help you find what you need:
Features
Applications
| Optical System Type | Binocular |
| Tube Inclination | 30° |
| Rotatable | 360° |
| Eyepiece | Magnification: 10x Type: Widefield Field Diameter: 0.7" (18 mm) |
| Nosepiece | Positions: 4 Pitch: Reverse |
| Illumination | Technique: Brightfield Type: Achromatic |
| Objective Magnification | 4x, 10x, 40x, 100x |
| Stage | Type: Mechanical Shape: Rectangular Dimensions: 6.3 x 5.5" (160 x 140 mm) |
| Focusing Range | 1.6" (40 mm) |
| Condenser | Type: Abbe 1.25 N.A. w/ Iris Diaphragm Focusing Control: Rack & Pinion |
| Illumination | Type: 20W Variable quartz halogen Koehler: Field Diaphragm Filter Holder: On Collector |
| Dimensions | 8.27 x 7.09 x 14.97" (210 x 180 x 380 mm) |
| Weight | 15.4 lbs (7.0 kg) |
| Optical System Type | Binocular |
| Tube Inclination | 30° |
| Rotatable | 360° |
| Eyepiece | Magnification: 10x Type: Widefield Field Diameter: 0.7" (18 mm) |
| Nosepiece | Positions: 4 Pitch: Reverse |
| Illumination | Technique: Brightfield Type: Achromatic |
| Objective Magnification | 4x, 10x, 40x, 100x |
| Stage | Type: Mechanical Shape: Rectangular Dimensions: 6.3 x 5.5" (160 x 140 mm) |
| Focusing Range | 1.6" (40 mm) |
| Condenser | Type: Abbe 1.25 N.A. w/ Iris Diaphragm Focusing Control: Rack & Pinion |
| Illumination | Type: 20W Variable quartz halogen Koehler: Field Diaphragm Filter Holder: On Collector |
| Dimensions | 8.27 x 7.09 x 14.97" (210 x 180 x 380 mm) |
| Weight | 15.4 lbs (7.0 kg) |
