This is a handheld optical power meter with a large-area Silicon detector optimized for multimode, ribbon fiber, and plastic optical fiber (POF). With an integrated Visual Fault Locator (VFL), ISO/IEC 17025 traceable calibration, and compact rugged design, it is ideal for LAN, broadband, and visible/NIR fiber testing applications.
This is a handheld optical power meter with a large-area Silicon detector optimized for multimode, ribbon fiber, and plastic optical fiber (POF). With an integrated Visual Fault Locator (VFL), ISO/IEC 17025 traceable calibration, and compact rugged design, it is ideal for LAN, broadband, and visible/NIR fiber testing applications.
Features
Detector Type | XL Silicon (Si5) large-area detector for multimode, ribbon, and POF |
Response Wavelength | 400 to ~1100 nm |
Calibration Wavelengths | 470, 520, 660, 780, 820, 850, 910, 940, 980 nm |
Power Range | Approximately +15 to -50 dBm (typical for XL-Si5) |
Tone and Autotest Sensitivity | Up to -40 dBm |
Midrange Linearity | 0.06 dB (typical) |
Calibration Accuracy | ±5% (typical, ~0.25 dB) |
Polarization Sensitivity | <0.05 dB (typical) |
Total Uncertainty | 0.5 dB |
Short-Term Stability | 0.03 dB (typical) |
Memory | 1000 4-λ tests with timestamp Unlimited with USB key |
Interfaces | USB-micro for power/software USB-A for memory key |
Power | 2 × AA Alkaline/Lithium 2 × NiMH rechargeable via USB |
Battery Life | Up to 1000 hours (laser and backlight off) 200 hours in blink mode |
Display | 2.9 x 2.2" (74 x 55 mm) high contrast LCD |
Case | Polycarbonate with rubber edges Moisture resistant 1 m drop-tested |
Temperature | Operating: 5 to 131°F (-15 to 55°C) Storage: -13 to 158°F (-25 to 70°C) |
Relative Humidity | 0 to 95% |
Warranty | 3 years |
Dimensions | 7.5 x 4.1 x 1.4" (190 x 105 x 35 mm) |
Weight | 0.92 lbs (0.42 kg) |
Shipping Weight | 3.3 lbs (1.5 kg) |
