Image is for reference only, refer to product info for complete details.
Ideal for industrial applications, this stainless steel pressure gauge is resistant to corrosion from both environment and media. Glycerin-filled for severe service with a paper tag, glass lens, and an attractive crimp ring design. In addition, it has a pressure range of 0 to 60 psi.
Ideal for industrial applications, this stainless steel pressure gauge is resistant to corrosion from both environment and media. Glycerin-filled for severe service with a paper tag, glass lens, and an attractive crimp ring design. In addition, it has a pressure range of 0 to 60 psi.
Features
Applications
| Pressure Range | 0 to 60 psi |
| Accuracy | 2 - 1.6 - 2%, ASME grade B+ |
| Ambient/Process Limits | -40/150°F (-40/65.56°C) |
| Maximum Working Pressure | Stable = 100% Momentary = 110% of scale |
| Case Type | 304SS, case with crimped ring |
| Tube and Socket | 316SS |
| Mount Type | Center back |
| Connection | ¼" NPT |
| Case Fill | Glycerin |
| Lens | Plastic |
| Option | Paper tag |
| Environmental Protection | NEMA 4X/IP65 |
| Dial Size | 2.5" (63.5 mm) |
| Dimensions | 3.5 x 1.2 x Ø2.68" (88.9 x 30.48 x Ø68.1 mm) |
| Weight | 0.4 lbs (181.44 g) |
