Image is for reference only, refer to product info for complete details.
Ideal for industrial applications, this stainless steel pressure gauge is resistant to corrosion from both environment and media. Glycerin-filled for severe service and has an attractive crimp ring design with a pressure range of 0 to 30 psi.
Ideal for industrial applications, this stainless steel pressure gauge is resistant to corrosion from both environment and media. Glycerin-filled for severe service and has an attractive crimp ring design with a pressure range of 0 to 30 psi.
Features
Applications
| Pressure Range | 0 to 30 psi |
| Accuracy | 2 - 1.6 - 2%, ASME grade B+ |
| Ambient/Process Limits | -40/150°F (-40/65.56°C) |
| Maximum Working Pressure | Stable = 100% Momentary = 110% of scale |
| Case Type | 304SS, case with crimped ring |
| Tube and Socket | 316SS |
| Mount Type | Bottom |
| Connection | ¼" NPT |
| Case Fill | Glycerin |
| Wetted Materials | Tube: 316SS Socket: 316SS |
| Other Materials | Case: 304SS Ring: 304SS Dial: White aluminum, black letters Case-to-Socket: Screw connection |
| Environmental Protection | NEMA 4X/IP65 |
| Dial Size | 2.5" (63.5 mm) |
| Dimensions | 3.5 x 1.2 x Ø2.68" (88.9 x 30.48 x Ø68.1 mm) |
| Weight | 0.4 lbs (181.44 g) |
| Pressure Range | 0 to 30 psi |
| Accuracy | 2 - 1.6 - 2%, ASME grade B+ |
| Ambient/Process Limits | -40/150°F (-40/65.56°C) |
| Maximum Working Pressure | Stable = 100% Momentary = 110% of scale |
| Case Type | 304SS, case with crimped ring |
| Tube and Socket | 316SS |
| Mount Type | Bottom |
| Connection | ¼" NPT |
| Case Fill | Glycerin |
| Wetted Materials | Tube: 316SS Socket: 316SS |
| Other Materials | Case: 304SS Ring: 304SS Dial: White aluminum, black letters Case-to-Socket: Screw connection |
| Environmental Protection | NEMA 4X/IP65 |
| Dial Size | 2.5" (63.5 mm) |
| Dimensions | 3.5 x 1.2 x Ø2.68" (88.9 x 30.48 x Ø68.1 mm) |
| Weight | 0.4 lbs (181.44 g) |
