Ideal for ambient corrosion and vibration, this industrial stainless/brass gauge is fillable for vibration applications with a stainless steel case and a ring for corrosion defiance. In addition, it features a dial size of 2.5" (63.5 mm) and a pressure range of 0 to 30 psi.
Ideal for ambient corrosion and vibration, this industrial stainless/brass gauge is fillable for vibration applications with a stainless steel case and a ring for corrosion defiance. In addition, it features a dial size of 2.5" (63.5 mm) and a pressure range of 0 to 30 psi.
Features
Applications
| Pressure Range | 0 to 30 psi |
| Accuracy | 3 – 2 – 3%, ASME grade B |
| Temperature Range Limit | Ambient: -40 to 140°F (-40 to 60°C) Process: -40 to 140°F (-40 to 60°C) |
| Lens | Glass |
| Mount Type | Bottom |
| Connection | ¼" NPT |
| Case Type | 304SS crimped ring |
| Tube and Socket | Copper alloy |
| Environmental Protection | NEMA 4X/IP65 |
| Restrictor Screw | Built-in, non-removable |
| Fillable | Yes |
| Dial Size | 2.5" (63.5 mm) |
| Weight | 0.25 lbs |
| Pressure Range | 0 to 30 psi |
| Accuracy | 3 – 2 – 3%, ASME grade B |
| Temperature Range Limit | Ambient: -40 to 140°F (-40 to 60°C) Process: -40 to 140°F (-40 to 60°C) |
| Lens | Glass |
| Mount Type | Bottom |
| Connection | ¼" NPT |
| Case Type | 304SS crimped ring |
| Tube and Socket | Copper alloy |
| Environmental Protection | NEMA 4X/IP65 |
| Restrictor Screw | Built-in, non-removable |
| Fillable | Yes |
| Dial Size | 2.5" (63.5 mm) |
| Weight | 0.25 lbs |
