NAVAC NRP8Di Vacuum Pump, 8 CFM

Model: NRP8Di | UPC: 811245030031

NAVAC NRP8Di Vacuum Pump, 8 CFM

Model: NRP8Di | UPC: 811245030031

NAVAC NRP8Di Vacuum Pump, 8 CFM

NAVAC NRP8Di Vacuum Pump, 8 CFM

Sale Price $734.00 USD
Regular Price $1028.00 USD
Availability 2 in Stock
Quantity

NAVAC NRP8Di Offers

Industry first brushless DC inverter-driven vacuum pump provides high-efficiency and one of the lightest vacuum pumps in its class. It saves energy and makes it easy to carry. Despite of its light weight, this vacuum pump is nonetheless powerful with twin-cylinder ensuring best-in-class ultimate vacuum at 15 Microns.

The automatic solenoid valve prevents oil back and reduces vacuum decay during a power outage or accidental shut off. It’s particularly useful when an extended evacuation is needed for deep vacuum or large HVAC/R systems with long pipe lines, so that whatever vacuum level achieved before the power outage would be largely preserved.

This product comes with other features and benefits, such as large oil tank at 20 oz (0.59 liters) capacity extending usage time between the oil changes, Recessed power switch protecting it from tripping and rain, and gas ballast for evacuating systems with high moisture content.

Features

  • Featuring a digital control interface, the unit offers unsurpassed intuitiveness with features such as task reminder, extended evacuation for improved vacuum, and precision vacuum measurement down to micron levels with LCD digital display
  • Brushless DC-driven 6 cfm vacuum pump weighting only 28 lbs (3.62 kg)
  • Digital Control Interface with built-in micron gauge
  • Built-in solenoid valve
  • It comes with ¼”, 3/8” and ½” inlet ports

Applications

  • HVAC/R systems
  • Automotive industry
  • Leak detection
  • Refrigeration
  • Industrial processes

NAVAC NRP8Di Specifications

Flow Rate 8 CFM
Ultimate Vacuum 15 Micron
Pump Design Dual stage
Motor Power 3/4 HP
Inlet Ports 1/4", 3/8", 1/2" Flare
Power Supply 115 V / 60 Hz
RLA 6 A
Oil Capacity 17.6 oz (0.59 liters)
Dimensions 14 x 5.3 x 11.9" (356 x 135 x 302 mm)
Weight 28 lbs (12.7 kg)
Click here for complete specifications on the NAVAC NRP8Di

What's included with the NAVAC NRP8Di

  • Vacuum Pump
  • Two-Year Warranty

Ask a question about NAVAC NRP8Di Vacuum Pump, 8 CFM

Customer Reviews for the NAVAC NRP8Di
