Megger MIT430-TC2 1000V Insulation Tester

Model: MIT430-TC2 | Order No: 1001-369

Megger MIT430-TC2 1000V Insulation Tester-

Downloads:

More Megger Products

Ask an Expert

Megger MIT430-TC2 1000V Insulation Tester

Model: MIT430-TC2 | Order No: 1001-369

Analog/Digital Insulation Tester - 50/100/250/500/1000V + 600V Cat IV + PI & DAR + Result Storage + Download.

Analog/Digital Insulation Tester - 50/100/250/500/1000V + 600V Cat IV + PI & DAR + Result Storage + Download.

Discontinued!

This product has been discontinued and is no longer available. There is no direct replacement. Don't worry, we have some options to help you find what you need:

Visit our Insulation Resistance Testers / Megohmmeters category for similar products.

Or let's do a search and help you find what you need:

Megger MIT430-TC2 Insulation Resistance and Continuity Tester

The Megger MIT430-TC2 Insulation Resistance and Continuity Testers Features: test result storage and Bluetooth wireless data transfer.

The Megger MIT430-TC2 insulation resistance and continuity tester has been designed specifically for use within the telecommunications industry. Unique telecommunications-related Features: include a soft canvas carrying bag with shoulder strap and rugged snap hook to attach to a tool belt, and a “bed of nails” test lead set.

The instrument allows the user to determine the condition of the insulation of the twisted copper cable pair, which could cause problems for services such as voice, video, and data or VOIP. When the insulation becomes weak or brittle, causing cracks or exposing copper within the cable, or water ingresses into the cable, the insulation resistance test will identify these situations immediately.

  • Insulation testing up to 1000 V and 200 GΩ
  • Patented analog arc and dual digital display
  • CAT IV 600 V rating
  • TRMS & DC Voltage measurement
  • Continuity testing at 200 mA or 20 mA down to 0.01
  • Pass/Fail limit alarms
  • PI/DAR and Timer function
  • Test result storage
  • Bluetooth® wireless data transfer
  • Three year product warranty
  • IP54 rated

Key Features

  • CAT IV 600 V rating - provides greater safety when testing at higher voltage levels
  • Adjustable insulation test voltages - provides 250 V to 1000 V or 50 V to 1000 V.
  • Dual digital display readout - allows display of complimentary test information simultaneously (for example: MΩ plus test voltage or MΩ plus leakage current)
  • Digital and analog arc display - includes not only the digital readout but also Megger's patented analog arc to replicate the response of a moving coil display
  • Exceptional measurement range from 20 GΩ to 200 GΩ - highest insulation test range available on the market, providing a superior range of measurement applications.
  • Choice of 20 mA or 200 mA continuity testing - allows user to select lower continuity range thus increasing battery life considerably
  • Continuity auto-test capability - enables real two-handed operation without the need to press the test button
  • Adjustable continuity limit alarm - allows pass/fail limits to be sent to speed testing
  • Automatically perform PI and DAR tests - user is able to quickly perform two important diagnostic tests. . . Polarization Index (PI) and Dielectric Absorption Ratio (DAR)
  • True RMS voltage measurement - allows accurate voltage measurement on noisy lines
  • Auto ranging voltage measurement - automatically adjusts range from millivolts to 600 V AC or DC, eliminating the need to keep changing ranging
  • Live circuit warning - automatically warns of contact to a live circuit, voltage is displayed and testing is inhibited
  • Auto fuse warning - warns of fuse failure automatically. No need to test the fuse manually.
  • Buzzer select button - enable or disable buzzer as required with resistance also displayed on the screen.
  • Stylish tapered design and center button placement - easy to use with either hand

Specifications (MIT400-EN)

*All quoted accuracies are at +20° C.
Insulation Nominal test voltages 250 V, 500 V, 1000 V
Insulation resistance range 20 GΩ
Range Full Scale Accuracy 1000 volts ±3% ±2 digits ±0.2% per GΩ 500 volts ±3% ±2 digits ±0.4% per GΩ 250 volts ±3% ±2 digits ±0.8% per GΩ
Analog range 1 GΩ full scale
Short Circuit Current 2 mA +0% -50%
Terminal voltage -0% +20% ±1 V
Test Current on load 1 mA at min. pass value of insulation specified in BS7671, HD384and IEC364, 2 mA max.
EN61557 Operating range 0.10 M½ to 1.00 GΩ
Leakage Current 10% ±3 digits
Voltage display 3% ±3 digits ±0.5% of rated voltage
Polarization Index (PI) 10 min/1 minute ratio
Dielectric Absorption Ratio (DAR) 60 sec/30 sec ratio
Notes (1) All ranges measure from 0.00 M½ upwards. (2) Above specifications only apply when high quality silicone leadsare being used.
Continuity
Measurement 0.01 ½ to 99.9 ½ (0 to 100 ½ on analog scale)
Accuracy ±3% ±2 digits (0 to 100 Ω)
Open circuit voltage 5 V ±1 V
Test current 200 mA (–0 mA +20 mA) (0.01 ½ to 9.99 Ω) 20mA (±1 mA ) (10.0 ½ to 99.9 Ω)
Zero offset at probe tips 0.10Ω typical
Lead resistance zeroing Up to 9.00 Ω
Buzzer Variable limit 1Ω, 2Ω, 5Ω,10Ω, 20Ω
Resistance
Measurement 0.01 kΩ to 1000 kΩ (0 to 1 MΩ on analog scale)
Accuracy ±3% ±2 digits Open circuit voltage 5 V ±1 V Short circuit current 20 µA ± 5 µA
Voltage range 0 to 600 V d.c. ±2% ±2 digits 10 mV to 600 V TRMS sinusoidal (40 to 400 Hz) ±2% ±2 digits 0 to 1000 V on Analog scale Unspecified input level 0 - 10 mV (40 to 400 Hz) For non-sinusoidal waveforms additional specification apply: ±3% ±2 digits 101 mV to 600 V TRMS and ±8% ±2 digits 10 mV to 100 mV TRMS
Default Voltmeter Operates at >25 V a.c. or d.c. on any range except OFF
Frequency 40 - 450 Hz (40 Hz - 99.9 Hz) ±0.5% ±1 digit (100 Hz to450 Hz)
Result storage
Capacity >1000 test results
Download Bluetooth wireless
Bluetooth Class Class II
Range up to 10 m
Power
Power Supply 5 x 1.5 V cells type IEC LR6 (AA, MN1500, HP7, AM3 R6HP) Alkaline NiMH rechargeable cells may be used. Battery life: 2200 insulation tests with duty cycle of 5 sec ON /55 sec OFF @ 1000 V into 1 MΩ
Dimensions
Instrument 220 x 92 x 50 mm (8.66 in. x 3.63 in. x 1.97 in.)
Instrument and case 456 x 178 x 89 mm (18 in. x 7 in. x 3.5 in.)
Weight
Instrument only 590 gms (20.73 oz.), 775 gms (27.22 oz.) with boot
Instrument and case 1.75kg (3.86 lb)
Fuse Use only a 500 mA (FF) 1000 V 32 x 6 mm ceramic fuse of highbreaking capacity HBC 50 kA minimum. Glass fuses MUST NOT be fitted.
Safety Protection The instruments meet EN 61010-1 (1995) to 600 V phase to earth, Category IV. Refer to safety warnings supplied.
E.M.C. In accordance with IEC 61326 including amendment No.1
Temperature effects
Temperature coefficient <0.1&Omega per °C up to 1 G&Omega
Environmental
Operating range -10 to +55° C
Operating humidity 90% RH at 40° C max.
Storage temperature range -25 to +70° C
Calibration Temperature +20° C
Maximum altitude 2000 m
Dust and water protection IP54 Protected against dust and splashing water
Click here for complete specifications on the Megger MIT430-TC2

What's included with the Megger MIT430-TC2

  • Megger MIT430-TC2 1000V Insulation Tester
Industrial and Power Applications Telecommunications Applications Special
Insulation Voltage range MIT400 MIT410 MIT420 MIT430 MIT480 MIT481 MIT485 MIT40X
10-100 V variable (2 GΩ - 20 GΩ)
50 V
100 V
250 V
500 V
1000 V
Insulation range 20 GΩ 100 GΩ 200 GΩ 200 GΩ 100 GΩ 200 GΩ 200 GΩ 2-20 GΩ
Leakage current display
INS test voltage display
Continuity Measurement
0.01 to 100 Ω
Variable current limit. 200 mA/20 mA
Fast buzzer- selectable threshold
k Ω range to 999 k Ω
Other functions and features
Live circuit warning at 50 V
Live circuit warning at 75 V
Default voltmeter
TRMS measurement to 600 V
Frequency Hz - 40 to 400 Hz
Capacitance (0.1 nf to 10 µF)
mV/transducer (0.1 to 19.99 V)
Backlight
Battery condition display
Insulation Timed - PI - DAR Tests
Test button plus lock button
Limit alarm pass band on INS
Auto power down
Result storage
Bluetooth downloading
Included Accessories
Red/black silicone lead set with clips
Protective rubber boot with built-in stand
Remote switch probe
Calibration certificate with product
Batteries
3 Year Warranty
