Hedland H913A-180 Variable Area Water-Based Fluid Flow Meter, 3" NPT, 20 to 180 GPM

Model: H913A-180

Be the first to review this product

Hedland H913A-180 Variable Area Water-Based Fluid Flow Meter, 3&quot; NPT, 20 to 180 GPM-

Image is for reference only, refer to product info for complete details.

Downloads: manual

More Hedland Products

Ask an Expert

Hedland H913A-180 Variable Area Water-Based Fluid Flow Meter, 3" NPT, 20 to 180 GPM

Model: H913A-180

Be the first to review this product

Monitor fluid flow rates of water and oil emulsions with this water-based fluid flow meter. Additionally, this meter is ideal for operators that need a quick visual indication of flow, without having to use additional products, and features an LPM of 50 to 650.

Sale Price	$2156.47 USD
Regular Price	$2423.00 USD
Availability	6 to 7 Weeks
Quantity	Quantity

Hedland H913A-180 Offers

Features

Direct reading
Install in any position
360° rotatable guard/scale
Easier-to-read linear scale
No flow straighteners or special piping required
Relatively insensitive to shock and vibration
Good viscosity stability
Calibrated for 1.0 S.G.
For 80/20 and other water/oil emulsions

Hedland H913A-180 Specifications

Flow Range
GPM	20 to 180
LPM	50 to 650
Pressure Drop
50% Flow PSI (BAR)	11 psi (0.76 bar)
100% Flow PSI (BAR)	17 psi (1.1 bar)
General Specifications
Pressure Rating	3500 psi/241 bar max. (800 psi/55 bar max. for 3" series) with a 3:1 safety factor
Accuracy	±2% of full scale ±7% of full scale for ¼" meters
Repeatability	±1%

What's included with the Hedland H913A-180

Hedland H913A-180 Variable Area Water-Based Fluid Flow Meter, 3" NPT, 20 to 180 GPM

manual for the Hedland H913A-180 Variable Area Water-Based Fluid Flow Meter, 3" NPT, 20 to 180 GPM

Ask a question about Hedland H913A-180 Variable Area Water-Based Fluid Flow Meter, 3" NPT, 20 to 180 GPM

Customer Reviews for the Hedland H913A-180
