Hedland H813A-150 Variable Area Water-Based Fluid Flow Meter, 1¼" NPT, 10 to 150 GPM

Model: H813A-150

Be the first to review this product

$Hedland H813A-150 Variable Area Water-Based Fluid Flow Meter, 1&frac14;&quot; NPT, 10 to 150 GPM-$

Image is for reference only, refer to product info for complete details.

Downloads: datasheet manual

More Hedland Products

Ask an Expert

Hedland H813A-150 Variable Area Water-Based Fluid Flow Meter, 1¼" NPT, 10 to 150 GPM

Model: H813A-150

Be the first to review this product

Monitor fluid flow rates of water and oil emulsions with this water-based fluid flow meter. Additionally, this meter is ideal for operators that need a quick visual indication of flow, without having to use additional products, and features an LPM of 50 to 560.

Sale Price	$890.89 USD
Regular Price	$1001.00 USD
Availability	1 to 2 Weeks
Quantity	Quantity

Hedland H813A-150 Offers

Features

Direct reading
Install in any position
360° rotatable guard/scale
Easier-to-read linear scale
No flow straighteners or special piping required
Relatively insensitive to shock and vibration
Good viscosity stability
Calibrated for 1.0 S.G.
For 80/20 and other water/oil emulsions

Hedland H813A-150 Specifications

Flow Range
GPM	10 to 150
LPM	50 to 560
Pressure Drop
50% Flow PSI (BAR)	10.5 psi (0.72 bar)
100% Flow PSI (BAR)	27.5 psi (1.9 bar)
Reverse 100% Flow PSI (BAR)	110 psi (7.6 bar)
General Specifications
Pressure Rating	3500 psi/241 bar max. (800 psi/55 bar max. for 3" series) with a 3:1 safety factor
Accuracy	±2% of full scale ±7% of full scale for ¼" meters
Repeatability	±1%

Click here for complete specifications on the Hedland H813A-150

What's included with the Hedland H813A-150

Hedland H813A-150 Variable Area Water-Based Fluid Flow Meter, 1¼" NPT, 10 to 150 GPM

datasheet for the Hedland H813A-150 Variable Area Water-Based Fluid Flow Meter, 1¼" NPT, 10 to 150 GPM manual for the Hedland H813A-150 Variable Area Water-Based Fluid Flow Meter, 1¼" NPT, 10 to 150 GPM

Ask a question about Hedland H813A-150 Variable Area Water-Based Fluid Flow Meter, 1¼" NPT, 10 to 150 GPM

Customer Reviews for the Hedland H813A-150

Description ➕➖

Hedland H813A-150 Offers

Features

Direct reading
Install in any position
360° rotatable guard/scale
Easier-to-read linear scale
No flow straighteners or special piping required
Relatively insensitive to shock and vibration
Good viscosity stability
Calibrated for 1.0 S.G.
For 80/20 and other water/oil emulsions

Specifications ➕➖

Hedland H813A-150 Specifications

Flow Range
GPM	10 to 150
LPM	50 to 560
Pressure Drop
50% Flow PSI (BAR)	10.5 psi (0.72 bar)
100% Flow PSI (BAR)	27.5 psi (1.9 bar)
Reverse 100% Flow PSI (BAR)	110 psi (7.6 bar)
General Specifications
Pressure Rating	3500 psi/241 bar max. (800 psi/55 bar max. for 3" series) with a 3:1 safety factor
Accuracy	±2% of full scale ±7% of full scale for ¼" meters
Repeatability	±1%
