The ultrasonic flowmeter (for 2" pipes) provides an accurate reading of liquid flow rate and accumulated flow. It is designed to support commercial irrigation applications.
The ultrasonic flowmeter (for 2" pipes) provides an accurate reading of liquid flow rate and accumulated flow. It is designed to support commercial irrigation applications.
Discontinued!
This product has been discontinued and is no longer available.
This is the direct replacement:
Features
Applications
| Operating Range |
Minimum: 0.92 GPM (3.48 L minimum) 0.1' per second Maximum: 138 GPM (522.39 L minimum) 15' per second |
| Maximum Water Pressure | 150 psi at 73°F (10 bar at 23°C) |
| Temperature Rating | Operating: 32 to 140°F (0 to 60°C) Storage: -20 to 160°F (-29 to 71°C) |
| Flow Range | 0.1 to 15 fps (0.03 to 4.57 m/s) |
| Accuracy | Typically ±2% of reading |
| Operating Pressure | 150 psi at 73°F (10 bar at 23°C) 100 psi at 140°F (7 bar at 60°C) |
| Output Frequency | 0 to 100 Hz |
| Pipe Size | 2" (51 mm) |
| Operating Range |
Minimum: 0.92 GPM (3.48 L minimum) 0.1' per second Maximum: 138 GPM (522.39 L minimum) 15' per second |
| Maximum Water Pressure | 150 psi at 73°F (10 bar at 23°C) |
| Temperature Rating | Operating: 32 to 140°F (0 to 60°C) Storage: -20 to 160°F (-29 to 71°C) |
| Flow Range | 0.1 to 15 fps (0.03 to 4.57 m/s) |
| Accuracy | Typically ±2% of reading |
| Operating Pressure | 150 psi at 73°F (10 bar at 23°C) 100 psi at 140°F (7 bar at 60°C) |
| Output Frequency | 0 to 100 Hz |
| Pipe Size | 2" (51 mm) |
