Extech PRC20 Microprocessor Calibrator/Thermometer

Model: PRC20 | UPC: 793950710210

Extech PRC20 Microprocessor Calibrator/Thermometer

Model: PRC20 | UPC: 793950710210

Measures eight thermocouple type devices (J, K, T, E, C, R, S and N) and provides precision output displayed as Centigrade/Fahrenheit or mV.

Measures eight thermocouple type devices (J, K, T, E, C, R, S and N) and provides precision output displayed as Centigrade/Fahrenheit or mV.

Sale Price $503.10 USD
Regular Price $559.00 USD
Availability 4 Days
Quantity

Add In-House Traceable Calibration to your PRC20

Add In-House Traceable Calibration to your PRC20


Recommended Accessories


Extech PRC20 Offers

Features

  • Source and measure 8 thermocouple type devices (J, K, T, E, C, R, S and N)
  • CJC - Cold Junction Compensation function
  • Up to five user adjustable calibration presets
  • Palm-sized double molded housing and large dot-matrix digital backlit LCD with thermocouple type indication
  • High accuracy calibration function simulates precision thermocouple outputs for use in calibrating thermometers, transmitters, controllers or recorders
  • Displays output in terms of millivolts or temperature based on thermocouple tables
  • Mini thermocouple connector
  • Large battery bank for extended work cycle
  • External power adapter for continuous work cycle

Applications

  • Lab Field Calibration
  • Engineering Research and Design
  • HVAC/R
  • Temperature Control Process Troubleshooting

Extech PRC20 Specifications

Type J Range -58 to 1832°F
Type K Range -58 to 2498°F
Type T Range -184 to 752°F
Type E Range -58 to 1382°F
Type C Range 32 to 3182°F
Type R/S Range 32 to 3182°F
Type N Range 58 to 2372°F
Voltage -10.00mV to +60.00mV
Resolution 0.1° (up to 999.9) or 1° (over 999.9°) for J, K, T, E ; 1° for R, N; 0.5° for C, S
Input Impedance 10 MΩ
Click here for complete specifications on the Extech PRC20

What's included with the Extech PRC20

  • Calibration Cables
  • 100V-240V AC Universal Adapter with 4 Plugs
  • 6x AA Batteries
  • Hard Carrying Case

Click on a category to view a selection of compatible accessories with the Extech PRC20 Microprocessor Calibrator/Thermometer.

Extech UA100-240 Universal AC Adaptor, 120 to 240V UA100-240
Includes 4 international plugs: US, EU, UK, AU.
