Dwyer HFA-1-22 In-Line Flow Monitor, 4 to 23SCFM

Model: HFA-1-22

Be the first to review this product

Dwyer HFA-1-22 In-Line Flow Monitor, 4 to 23SCFM-

Downloads: datasheet manual

More Dwyer Products

Ask an Expert

Dwyer HFA-1-22 In-Line Flow Monitor, 4 to 23SCFM

Model: HFA-1-22

Be the first to review this product

Using a ring magnet on the outside of the case, this monitor easily displays the airflow rate on your facility's line. The 0.25in (6.35mm) female NPT connection simplifies installation.

Discontinued!

This product has been discontinued and is no longer available. There is no direct replacement. Don't worry, we have some options to help you find what you need:

Visit our Variable Area Flowmeters category for similar products.

Or let's do a search and help you find what you need:

Dwyer HFA-1-22 Offers

With this Dwyer HFA-1-22 In-Line Flow Monitor on your air line, you can easily check the rate of airflow. The monitor is ideal for setting up pressure-relief valves, while the 0.25" (6.35 mm) female NPT connection allows easy connection to your existing line.

Features

Great for measuring air pressure in the line from 4 to 23 SCFM
Air moves through the monitor and pushes the orifice disk and transfer magnet, which moves a ring-shaped magnet on the outside of the center shaft to indicate the airflow rate
Ideal for setting pressure-relief valves
Built with an aluminum casing and Buna-N seals and a PTFE-coated Alnico magnet
Features a 0.25" (6.35 mm) female NPT connection for simple installation

Applications

Fluid Handling Equipment, Industrial Maintenance, Pulp and Paper Industry

Dwyer HFA-1-22 Specifications

Connection Size	0.25" (6.35 mm) female NPT
Air SCFM Range	4 to 23
Maximum Pressure Drop PSID	3.61
Wetted Materials	Aluminum (casing), Buna-N (seals), PTFE (magnet), stainless steel (disk)
Maximum Viscosity	500 SSU
Temperature Limits	240°F (116°C)
Pressure Limits	600 psig (41 bar)
Accuracy	±4% of full scale over the entire range, ±2.5% over center third of the measuring range
Repeatability	±1% of full scale

Click here for complete specifications on the Dwyer HFA-1-22
