Designed for 4in IPS PVC pipes, this flowmeter features 75 to 420GPM (Schedule 40) and 70 to 375GPM (Schedule 80) ratings.
Designed for 4in IPS PVC pipes, this flowmeter features 75 to 420GPM (Schedule 40) and 70 to 375GPM (Schedule 80) ratings.
Features
| Pipe Dimensions | Horizontal Installation: 4" Vertical Installation: 1.5", 2" |
| Maximum Working Pressure | 75 PSI (5.17 bar) at 70°F (21°C) |
| Max. Fluid Temperature | 190°F / 88°C at 0 PSI |
| Full Scale Accuracy | ±10% (5x pipe ID minimum inlet pipe length / 2x pipe ID min outlet pipe length) ±5% (10x pipe ID minimum inlet pipe length / 5x pipe ID min outlet pipe length) |
| Material | Meter Body: Acrylic Gasket: Neoprene Float: PVDF |
| Connection Type | Saddle |
| Pipe Capability | PVC Schedule 40 and Schedule 80 (12% higher reading on sch 80 pipe) Copper Tube Type K and L |
| Weight | 1" to 4" Pipe: 1 lbs. (.454kg) 6" and 8" Pipe: 2 lbs. (.907 kg) |
| Pipe Dimensions | Horizontal Installation: 4" Vertical Installation: 1.5", 2" |
| Maximum Working Pressure | 75 PSI (5.17 bar) at 70°F (21°C) |
| Max. Fluid Temperature | 190°F / 88°C at 0 PSI |
| Full Scale Accuracy | ±10% (5x pipe ID minimum inlet pipe length / 2x pipe ID min outlet pipe length) ±5% (10x pipe ID minimum inlet pipe length / 5x pipe ID min outlet pipe length) |
| Material | Meter Body: Acrylic Gasket: Neoprene Float: PVDF |
| Connection Type | Saddle |
| Pipe Capability | PVC Schedule 40 and Schedule 80 (12% higher reading on sch 80 pipe) Copper Tube Type K and L |
| Weight | 1" to 4" Pipe: 1 lbs. (.454kg) 6" and 8" Pipe: 2 lbs. (.907 kg) |
