B&K Precision 879B-220V Deluxe Universal LCR Meter, 220VAC Version

Model: 879B-220V

Be the first to review this product

B&amp;K Precision 879B-220V Deluxe Universal LCR Meter, 220VAC Version-

Downloads: datasheet manual

More B&K Products

Ask an Expert

B&K Precision 879B-220V Deluxe Universal LCR Meter, 220VAC Version

Model: 879B-220V

Be the first to review this product

This 40,000-count handheld LCR meter features quick and precise measurement of inductance, capacitance, resistance, impedance, Theta, DCR, and ESR.

Sale Price	$384.75 USD
Regular Price	$405.00 USD
Availability	2 to 3 Weeks
Quantity	Quantity

B&K 879B-220V Offers

Fast auto ranging and quick measurement configuration such as measurement parameter and test frequency selection make these meters very simple to operate. The meter also includes handy functions such as data hold, Min/Max/Average recording, tolerance sorting, and relative mode.

Measurement data can continuously transfer to a PC via the meter's mini USB interface, using either the provided data logging software or SCPI commands sent from a custom program.

Features

40,000 counts resolution on primary and 10,000 counts resolution on secondary display
L, C, R, and Z (879B & 880 only) primary measurements
Fast auto range design for rapid, easy component measurements
Relative mode
Visible and audible tolerance mode
Backlit display (879B & 880 only)
Data Hold and Min/Max/Average recording
USB (Virtual COM) interface
SCPI compliant commands for remote communication
Software for datalogging and front panel emulation available as free download
Configurable power-up-states

Applications

Passive Component Troubleshooting
Electronic Assembly
Quality Control (Component Sorting)

B&K 879B-220V Specifications

Measurement Parameters	L/C/R/Z/D/Q/0/ESR
Test Frequency Accuracy (0.02% of Actual Frequency)	Test Setting: 100 Hz, 120 Hz, 1 kHz, 10 kHz Actual Frequency: 1 kHz, 10 kHz
Tolerance Mode	1%, 5%, 10%, 20%
Backlit Display	Yes
Basic Accuracy	0.5%
Power Consumption	28 mA (under full power battery) for operation/ 2 µA after Power-off
Dimensions	7.5 x 3.5 x 1.6" (190 x 90 x 41 mm)
Weight	0.7 lbs (330 grams)

Click here for complete specifications on the B&K 879B-220V

What's included with the B&K 879B-220V

Deluxe Universal LCR Meter
Instruction Manual
Mini USB Interface Cable
Red & Black Banana to Alligator Test Leads
9V Battery
AC Adapter
