AMETEK Jofra RTC-157 Series Reference Temperature Calibrator

Downloads: datasheet manual

AMETEK Jofra RTC-157 Series Reference Temperature Calibrator

Compact and lightweight, this portable temperature calibrator offers accurate and reliable calibrations. With a temperature range of -49 to 311°F (-45 to 155°C), this calibrator features dynamic load compensation technology for perfect temperature uniformity, as well as increased heating and cooling speed.

Discontinued!

This product has been discontinued and is no longer available.
This is the direct replacement:

AMETEK Jofra RTCt-157 Series Reference Temperature Calibrators

Model: RTCt-157 Series | Order No: RTCt-157 Series

The RTCt-157 series ushers in a new era of precision and user-centricity in temperature calibration by offering a comprehensive feature set meticulously designed to improve your workflow. Wireless connectivity streamlines data transfer and facilitates remote monitoring, while innovative graphical presentations enhance clarity and expedite analysis.

Learn More

Jofra RTC-157 Offers

With a large color display, this portable temperature calibrator features excellent stability and dynamic load compensation.

Features

Patented DLC (dynamic load compensation) system for perfect temperature uniformity in the insert
Unique, intelligent sensors for plug n' play connection
USB connector for communication
Easy-to-read color VGA display with a perfect overview of the actual status
Intuitive, fast, and user-friendly navigation
Lightweight and easy to carry around
Functional carrying case design
Multi-hole insert kits covering all of the most used sensor sizes
High profile design and well-known, long lasting quality
Fast temperature calibration
Silent operation
Enhanced stability
Instrument setups
Maximum and minimum temperature
Auto-stepping
Sync output
Calibration on indication devices

Applications

Healthcare
Medical
Pharmaceutical
Biotechnology
Food industry

Jofra RTC-157 Specifications

Temperature
Range	At ambient 32°F (0°C): -71 to 311°F (-57 to 155°C) At ambient 73°F (23°C): -249 to 311°F (-45 to 155°C) At ambient 104°F (40°C): -24 to 311°F (-31 to 155°C)
Stability	±0.009°F (±0.005°C)
Radial Homogeneity (Difference Between Holes)	0.02°F (0.01°C)
Settings	Resolution: 1, 0.1, 0.01, or 0.001 Units: °C or °F or K
Heating Time	-49 to 73°F (-45 to 23°C): 7 minutes 73 to 311°F (23 to 155°C): 17 minutes
Cooling Time	311 to 212°F (155 to 100°C): 5 minutes 212 to 73°F (100 to -23°C): 10 minutes 73 to -22°F (23 to -30°C): 15 minutes -22 to -49°F (-30 to -45°C): 25 minutes
Time to Stability (Typical)	10 minutes
Immersion Depth	6.3" (160 mm)
General Specifications
Temperature	Operating: 32 to 104°F (0 to 40°C) Storage: -4 to 122°F (-20 to 50°C)
Humidity	5 to 90% RH, non-condensing
Protection Class	IP10
Dimensions	14.3 x 6.7 x 14.3" (362 x 171 x 363 mm)
Weight	23.2 lbs (10.5 kg)

Click here for complete specifications on the Jofra RTC-157

What's included with the Jofra RTC-157

Reference Temperature Calibrator
Traceable Certificate - Temperature Performance
Tool for Insertion Tubes
Set of Rubber Cones for Insulation Plugs
USB Cable
Mains Power Cable
User Manual
JofraCal Calibration Software

datasheet for the AMETEK Jofra RTC-157 Series Reference Temperature Calibrator manual for the AMETEK Jofra RTC-157 Series Reference Temperature Calibrator
