Compact and accurate, this handheld pressure calibrator combines pressure with an mA loop and is fully temperature compensated from -4 to 122°F (-20 to 50°C). Complete with a 30 and a 300 psi sensor, this dual sensor pressure calibrator provides reliable barometric pressure, pressure, current, voltage, or temperature measurements.
Compact and accurate, this handheld pressure calibrator combines pressure with an mA loop and is fully temperature compensated from -4 to 122°F (-20 to 50°C). Complete with a 30 and a 300 psi sensor, this dual sensor pressure calibrator provides reliable barometric pressure, pressure, current, voltage, or temperature measurements.
Compatible with pump systems, the single sensor pressure calibrator includes all effects of linearity, hysteresis, repeatability, temperature, and stability.
Features
Applications
| T-975 Pneumatic Hand Pump | -25 inHg to 580 psi / - 0.91 to 40 bar |
| Accuracy | 0 to 30% of range: ±(0.015% of full scale) 30 to 110% of range: ±(0.050% of reading) Vacuum : ±(0.05% of full scale) |
| Differential Pressure Range | 30 psi/300 psi |
| Pressure Sensor | Wetted materials: (wrench tight) 316 stainless steel, (finger tight) 316 stainless steel, and Viton (internal o-ring) Diaphragm seal fluid: silicone oil Connection: crystal CPF female |
| Barometric Reference | Accuracy: ±0.00725 psi, ±0.5 mbar Range: 10.153 to 15.954 psiA, 700.0 to 1100.0 mbarA |
| Current and Voltage Measurement | Connection: 4 mm jacks Maximum voltage: 45 VDC Current (mA) input accuracy: ±(0.015% of rdg + 0.002 mA), mA range: 0 to 55 mA Current (mA) output accuracy: ±(0.015 of rdg + 0.002 mA), range: 0 to 25 mA Voltage (VDC) input accuracy: ±(0.015 % of rdg + 2 mV), range: 0 to 30 VDC Loop power accuracy: ±(0.015% of rdg) + 0.02 Ω, range: 0 to 400 Ω |
| Temperature Range | -4 to 122°F (-20 to 50°C) |
| Enclosure | Rating: IP65 Housing: machined aluminum Keypad and labels: UV resistant silicone |
| Weight | 689 g (24.3 oz) |
| T-975 Pneumatic Hand Pump | -25 inHg to 580 psi / - 0.91 to 40 bar |
| Accuracy | 0 to 30% of range: ±(0.015% of full scale) 30 to 110% of range: ±(0.050% of reading) Vacuum : ±(0.05% of full scale) |
| Differential Pressure Range | 30 psi/300 psi |
| Pressure Sensor | Wetted materials: (wrench tight) 316 stainless steel, (finger tight) 316 stainless steel, and Viton (internal o-ring) Diaphragm seal fluid: silicone oil Connection: crystal CPF female |
| Barometric Reference | Accuracy: ±0.00725 psi, ±0.5 mbar Range: 10.153 to 15.954 psiA, 700.0 to 1100.0 mbarA |
| Current and Voltage Measurement | Connection: 4 mm jacks Maximum voltage: 45 VDC Current (mA) input accuracy: ±(0.015% of rdg + 0.002 mA), mA range: 0 to 55 mA Current (mA) output accuracy: ±(0.015 of rdg + 0.002 mA), range: 0 to 25 mA Voltage (VDC) input accuracy: ±(0.015 % of rdg + 2 mV), range: 0 to 30 VDC Loop power accuracy: ±(0.015% of rdg) + 0.02 Ω, range: 0 to 400 Ω |
| Temperature Range | -4 to 122°F (-20 to 50°C) |
| Enclosure | Rating: IP65 Housing: machined aluminum Keypad and labels: UV resistant silicone |
| Weight | 689 g (24.3 oz) |
