Accuenergy AcuCT-3050-3000:333 Split Core Current Transformer, 3 x 5", 3000 A:333 mV

Model: AcuCT-3050-3000:333

Accuenergy AcuCT-3050-3000:333 Split Core Current Transformer, 3 x 5", 3000 A:333 mV-

Downloads: datasheet

More Accuenergy Products

Ask an Expert

Accuenergy AcuCT-3050-3000:333 Split Core Current Transformer, 3 x 5", 3000 A:333 mV

Model: AcuCT-3050-3000:333

Conventional split core current transformer features a 333 mV low voltage output for safe opening, a window size of 3 x 5", and current input of 3000 A.

Conventional split core current transformer features a 333 mV low voltage output for safe opening, a window size of 3 x 5", and current input of 3000 A.

Sale Price $115.00 USD
Regular Price $125.00 USD
Availability 7 to 8 Weeks
Quantity

Accuenergy AcuCT-3050-3000:333 Offers

These split core CTs permit quick and easy installation without disconnecting cables and are ideal for low cost energy efficiency and energy management systems.

Features

  • Conventional 333 mV split-core style CT
  • Available in a variety of sizes and current input ranges from 20A to 5000A AC
  • 0.5% accuracy from 10 to 120% of rated current
  • Internal precision burden resistor across the secondary winding of the CT provides a safe low voltage output
  • Permits safe opening of the secondary
  • UL recognized

Accuenergy AcuCT-3050-3000:333 Specifications

Input Ranges 40A to 3000A
Rated Option 333mV
Window Sizes 3 x 5" (76.2 x 127mm)
Exterior Dimensions 5.748 x 7.5 x 1.402" (146 x 190.5 x 35.6mm)
Accuracy  0.5%
Standard/Certifications UR, CE, RoHS
Form Factor Rectangle Split Core
Click here for complete specifications on the Accuenergy AcuCT-3050-3000:333

What's included with the Accuenergy AcuCT-3050-3000:333

  • Accuenergy AcuCT-3050-3000:333 Split Core Current Transformer, 3 x 5", 3000 A:333 mV
datasheet for the Accuenergy AcuCT-3050-3000:333 Split Core Current Transformer, 3 x 5", 3000 A:333 mV

Ask a question about Accuenergy AcuCT-3050-3000:333 Split Core Current Transformer, 3 x 5", 3000 A:333 mV

Customer Reviews for the Accuenergy AcuCT-3050-3000:333

Accuenergy AcuCT-3050-3000:333 Offers

These split core CTs permit quick and easy installation without disconnecting cables and are ideal for low cost energy efficiency and energy management systems.

Features

  • Conventional 333 mV split-core style CT
  • Available in a variety of sizes and current input ranges from 20A to 5000A AC
  • 0.5% accuracy from 10 to 120% of rated current
  • Internal precision burden resistor across the secondary winding of the CT provides a safe low voltage output
  • Permits safe opening of the secondary
  • UL recognized
Show More...

Accuenergy AcuCT-3050-3000:333 Specifications

Input Ranges 40A to 3000A
Rated Option 333mV
Window Sizes 3 x 5" (76.2 x 127mm)
Exterior Dimensions 5.748 x 7.5 x 1.402" (146 x 190.5 x 35.6mm)
Accuracy  0.5%
Standard/Certifications UR, CE, RoHS
Form Factor Rectangle Split Core
Click here for complete specifications on the Accuenergy AcuCT-3050-3000:333

What's included with the Accuenergy AcuCT-3050-3000:333

  • Accuenergy AcuCT-3050-3000:333 Split Core Current Transformer, 3 x 5", 3000 A:333 mV
datasheet for the Accuenergy AcuCT-3050-3000:333 Split Core Current Transformer, 3 x 5", 3000 A:333 mV

Ask a question about Accuenergy AcuCT-3050-3000:333 Split Core Current Transformer, 3 x 5", 3000 A:333 mV

Customer Reviews for the Accuenergy AcuCT-3050-3000:333
